Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: Stego
  • Model Number: KTS 011
  • Usage: Industrial
  • Theory: Temperature Controller
  • Accuracy: max. 90 % RH (non-condensing)
  • Temperature range: -20 to +80°C (-49 to +176°F)
  • Switch temperature difference: 7K(±4K tolerance)
  • Sener element: thermostatic bimetal
  • Contact type: snap-action contact
  • Service type: >100000 cycles
  • Max.Switching capacity: 250VAC,10(2)A 120VAC,15(2)A DC 30W
  • Connection: 2-pole terminal,clamping torque 0.5Nm max:rigid wire 2.5 mm2
  • Mounting: clip for 35mm DIN rail
  • Dimensions: 60*33*43mm
  • Weight: approx.40g
  • Protection type: IP20

Packaging & Delivery

Packaging Details: Standard Export Packing
Delivery Detail: In 5 days
2013 new design different type of thermostat KTS 011



1. Model: KTS 011/KTO 011
2. CE certificate
3. 2 years warrant



Product Detail

KTO 011: Thermostat (normally closed); contact breaker for regulating heatersdifferent type of thermostat

KTS  011: Thermostat  (normally  open);  contact  maker  for  regulating  of  filter  fans  and  heat exchangers or for switching signal devised when temperature limit has been exceeded.



 different type of thermostat

Technical Data

Switch temperature difference                      7K (± 4K tolerance)
Sensor elementthermostatic bimetal
Contact typesnap-action contact
Service life> 100,000 cycles
Max. Switching capacity250VAC, 10 (2) A
120VAC, 15 (2) A
DC 30W
EMCacc.to EN 55014-1-2, EN61000-3-2, EN61000-3-3
Connection2-pole terminal, clamping torque 0.5Nm max.: rigid wire 2.5mm² stranded wire (with wire end ferrule) 1.5mm²
Mountingclip for 35mm DIN rail, EN60715 (or for exit filter EF 118 Series)
Casingplastic according to UL94 V-0, light grey
Dimensions60 x 33 x 43mm
Weightapprox. 40g
Fitting positionvariable
Operating / Storage temperature-20 to +80°C (-49 to +176°F)
Operating / Storage humiditymax. 90 % RH (non-condensing)
Protection typeIP20



Product Detail

different type of thermostat

different type of thermostat different type of thermostat

Example of Connection

different type of thermostatdifferent type of thermostat



Other Similar Product

different type of thermostat

Other Information

Setting range                   Art. No. Contact Breaker (NC)                             Art. No. Contact Maker  (NO)        Approvals
0 to +60°C01140.0-0001141.0-00VDE
-10 to +50°C01142.0-0001143.0-00VDE + UL File No. E164102
+20 to +80°C01159.0-0001158.0-00VDE + UL File No. E164102
+32 to +140°F01140.9-0001141.9-00VDE + UL File No. E164102
+14 to +122°F01142.9-0001143.9-00VDE + UL File No. E164102
0 to +60°C01146.9-0001147.9-00VDE + UL File No. E164102
