Quick Details

  • Electric Heater Type: Convector Heater
  • Heating Element: PTC
  • Installation: Portable
  • Certification: CE, RoHS
  • Function: Adjustable Thermostat
  • Use: Industrial Cabinet
  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: SAIP
  • Model Number: CS 060
  • Operating voltage: 120-240VAC/DC (other voltages on request)
  • Heating element: PTC resistor-temperature limiting
  • Casing: Plastic according to UL94-V-0
  • Protection type: IP20/II
  • Approvals: CE

Packaging & Delivery

Packaging Details Standard Packing Method.
Delivery Time One week after prepaid.

Specifications

Touch-Safe Heater CS 060 Series 50W-150W
1.Electric Heater, PTC Heater
2.Pressure clamp conectors
3.Dynamic heating up
4.Wid



         ----To Creat Product That Deliver HappineseTo Everyone





Heater Semiconductor Industrial-Heater HGL 046







Advantage



1. Low surface temperature
2. Integrated thermostat
3. Quick mounting due to clip fixing
4. Double insulated (plastic)
5. Wide voltage range
6. Small size



    Touch-safe heater for the use in enclosures with electrical/electronical components. The design of the heater supports the natural convection which results in a high air-current of warm air. The surface temperatures on the accessible side surfaces of the housing are kept down as a result of the heater design. This model with plug-in thermostat does not require additional wiring. The heaters are designed for permanent operation. This heater is also available in a version without thermostat (CS 060).

semiconductor industrial heater semiconductor industrial heater semiconductor industrial heater semiconductor industrial heater semiconductor industrial heater semiconductor industrial heater semiconductor industrial heater semiconductor industrial



Technical Date


Operating voltage 120-240V AC* (min. 110V, max. 265V)
Heating capacity see table
Heating element PTC resistor - temperature limiting
Surface temperature <80°C(176°F), except upper protective grille
Connection4-pole terminal 2.5mm2, torque 0.8Nm max.
Casingplastic according to UL94 V-0, black
Mountingclip for 35mm DIN rail, EN 50022
Fitting position vertical
Operating / Storage temperature -20 to +70°C (-4 to +158°F) / -45 to +70°C (-49 to +158°F)
Protection type / Protection class IP30 / 2(double insulated)
Noteother voltages on request

*Operating with voltages below 140V AC/DC reduces heating performance by approx. 10%.





Drawing





Correct Connection







Setting Range



Art.No.Heating capacity1) Inrush current max. Air outlet temperature2) Switch-off temperature3)Starting temperature3)DimensionsWeight (approx.)
06001.0-0050W2.5A+86°C (186.8°F)+15°C (59°F)+5°C (41°F)110×60×90mm0.30kg
06002.0-0050W2.5A+86°C (186.8°F)+25°C (77°F)+15°C (59°F)110×60×90mm0.30kg
06011.0-00100W4.5A+120°C (248°F)+15°C (59°F)+5°C (41°F)110×60×90mm0.30kg
06012.0-00100W4.5A+120°C (248°F)+25°C (77°F)+15°C (59°F)110×60×90mm0.30kg
06021.0-00150W8A+145°C (293°F)+15°C (59°F)+5°C (41°F)150×60×90mm0.50kg
06022.0-00150W8A+145°C (293°F)+25°C (77°F)+15°C (59°F)150×60×90mm0.50kg
1) ambient temperature - see Heating capacity / Ambient temperature diagram; 2) measured 50mm above protective grille; 3) tolerance of ± 5k;
